Car Accessory Door Window EPDM Rubber Weather Seal Strip

Short Description:

Automobile sealing strip is one of the important parts of automobiles. It is widely used in doors, windows, body, sunroof, engine box and backup (luggage) box, etc. It has the functions of sound insulation, dustproof, water seepage prevention and shock absorption. Maintain and maintain the small environment in the car, thus playing an important role in protecting the occupants, electromechanical devices and accessories in the car.

Send email to us

Product Detail

Common Questions

FAQ

Product Tags

Specifications

1.Door Window seal strip
2.Good resistance to aging,ozone;
3.Short lead time;

Item		Performance Index
Hardness (Shore A)		60~70
Tensile Strength (Mpa)		≥8
Elongation at breakage (%)		300
Hot air aging (70±2)°C/70h	Hardness changes, Shore A	0~+5
	Tensile strength changes,%	-15~+15
	Break elongation changes,%	-25~0
Water proof (80±2)°C/120h	Hardness changes,Shore A	0~+5
	Tensile strength changes,%	-15~+15
	Break elongation changes,%	-25~0
Compression set	(23±2)°C/72h	≤35
Compression set	(70±2)°C/24h	≤50
Brittleness temperature °C	No more than	-40
Ozone resistance	Stretch 20%,(40±2) °C/72h Ozone concentration (2±0.2)*10^-6	No Crack
Polluting		Light pollution
Causticity (100±2) °C/24h		Not turn to black

Our product passes the performance test for several years, and widely used in somewhere subway in china.
It located in the important status among the same industry:And the same time, exported to USA,German,
Netherlands,Russia,Kazakhstan,Iran,Saudi Arabia,Brazil and so on.Special in Russia, below 55 °C, our product still have a good performance .

Product Classification

EPDM Solid Rubber Strip,
EPDM Foamed Rubber Strip,
EPDM Flame Retardant Rubber,
EPDM Cold Resistant Rubber.

Usage

The application fields include:Automobile, construction, machinery, electronics and furniture making.

Product Features

1>.EPDM as raw material,very strong anti-old chemical property,durable,convenient installaion,beauty appearance
2>.A wide temperature range resistance (-40 ~ +120 )
3>.EPDM material used to make surface smooth and , good elasticity, good foam evenly, waterproof performance of first-class,
anti-ozone, anti-aging, bears the resolver performance to be good.

Application

Railcars, automobile, steamboat, industrial electrical equipment, building door & window, construction machinery,construction bridge and tunnel etc.
Automotive:Door, truck, truck crap, window seals spacers for wheel wells, window weather striping
Building products:Curtain wall frames, OEM window seals, door seals slider door seals, tract and channel seals
Window and door:Various door seals, edge guards, egress window frames, garage door seals.
Containers:Drums, barrels, safes and case seals.

Advantages

Compared with the traditional wooden, steel and aluminum profiles, window seal strip have the following strong points:
1.Good endurance
2.Fine air proof.This means that it can save 10% of energy.
3.It can effectively reduce the noise outside compares to the traditional ones.
4.Rubber profiles are easy to process, and can save time and labor.
5.Some profiles are push-and-pull type
6.High elasticity material
7.It is convenient to store and easy to install,
8.This product is good looking
9.Available in various colors.
10.High precision & low tolerance

Note

1.Customers design or logos highly welcome
2.Comptitive price and prompt delivery
3.Packing:Cartons or According to customers'requrements
4.Delivery time :7-15days
